C006244_01_CR4100_QuickStart_Guide

4.0 - Conguring the CR4100 Bar Code Reader - Advanced

Please refer to C005435_CR1000_CR8000_ConguraonGuide.pdf for advanced conguraon features.

4.1 - Tesng the CR4100 Bar Code Reader

1. Click the Windows START icon on the screen of the CR4100 (Figure 14).

2. Click on Cortex Mobile (Figure 15) Cortex Mobile is the bar code reader conguraon tool.

3. You will see a pop-up which states “Inializing Scanner” (Figure 16).

4. Aer the pop-up disappears, you will see a Data Matrix icon in the lower right hand corner of the screen (Figure 17) Click on the

Data Matrix icon. A pop-up will appear.

5. Click on Result Window opon.

6. A Scanning Result window will appear (Figure 27).

7. Press the Orange scan buon below the logo.

8. Align the blue bar over the bar code. The bar code reader is omnidireconal, so the bar code can be in any orientaon to

achieve a good read.

9. The bar code data will appear in the result window along with an esmated me to decode the bar code.

4.2 - Reseng the CR4100

Using the stylus, press and hold the reset buon for 1 second (Figure 28).

All running programs will be terminated and any working les or data that is not saved may

be lost. Any stored data will NOT be lost.

Figure 27

Figure 28
