C002332_15_CR3_User_Manual 58

Save Settings

6.4 - Reader Text Commands

Enabling Reader Text Commands allows the CR3 to accept text commands via RS-232 or RF commmunication. Scan

the following codes to enable/disable reader text commands:

Reader Text Commands On Reader Text Commands Off - Default

Note: Text commands can only be sent to the reader when it is active. Refer to Reader-Host Interface Control Document

for more information.

6.3 - Erase Prex and Sufx Settings

Scan the following codes to erase all prex and sufx data.

Erase Prex & Sufx Data
