Code Reader™ 3500 (CR3500) - Cabled

Quickstart Guide

C004418_03_CR3500_Cabled_Quickstart

Included with your Cabled CR3500

Depending on the reader conguraon ordered, you will have received some of the

following with your CR3500:

Blank Baery Cartridge H2 Handle

USB Cable RS232 Cable

Installing a Blank Baery Cartridge

1. To install a blank baery cartridge, place the plasc

tab on the boom of the baery cartridge into the

slot on the reader. Slide the locking mechanism up,

and press the baery into place. Slide the locking

mechanism down to secure the baery.

2. To detach a baery, slide the locking mechanism on

the reader up and pull the baery cartridge up and

away from the slot on the reader.

CR3500’s unique

targeng funcon uses

two converging targeng

LEDs to guide the user to

opmal reading range.

Reading Tips

Quick Tips

1. Press either trigger buon to turn the reader on, or to scan a bar code.

2. Press the So Key, under ‘Opons’ to: manually enter data, view stored data, connect to a

Bluetooth device, send all stored data to a PC, and change reader sengs.

3. Use the arrow buons to navigate through lists, data and more.

4. Use the Enter buon to select an item.

Visit www.codecorp.com to download the CR3500 User Manual for a complete reference guide of

CR3500 funcons.

The reader is too far from a

bar code (more than 12”

from the bar code reader).

The reader is too close to a

bar code (less than 1”

from the bar code reader).

The opmal distance to read

most bar codes is 3-4” away

from the bar code reader.
